Overview
Multiple Choices Endless Possibilities
Available in F600 and F1200 sizes with a 16:9 aspect ratio.
Exclusive Patented Tri-Pixel Technology
Compatible with COB real pixels, COB virtual pixels,and SMD technology.
High Contrast Ratio
10,000:1 contrast, the image is clear and bright, with details fully revealed.
Wider Viewing Angle
Ultra-wide viewing Angle, up to 170°/170°.
SPECIFICATIONS-F600
Category
Module Resolution(W×H)
Unit Composition(W×H)
Cabinet Resolution(W×H)
Average Power Consumption(W/m²)
Cabinet Weight(kg)
Contrast Ratio
Brightness(nits)
| F600C07 | F600C09 | F600C12 | F600C15 | F600C18 | F600S12 | F600S15 | F600S18 | F600S20 | F600S23 |
| 384x216 | 320x180 | 240x135 | 192x108 | 160x90 | 240x135 | 192x108 | 160x90 | 144x81 | 128x72 |
| 2x2 | 2x2 | 2x2 | 2x2 | 2x2 | 2x2 | 2x2 | 2x2 | 2x2 | 2x2 |
| 768x432 | 640x360 | 480x270 | 384x216 | 320x180 | 180x270 | 384x216 | 320x180 | 288x162 | 256x144 |
| 160 | 160 | 160 | 140 | 140 | 200 | 190 | 170 | 160 | 160 |
| 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 |
| 10000:1 | 10000:1 | 10000:1 | 10000:1 | 10000：1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 |
| 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) |
|
SPECIFICATIONS-F1200
Category
Module Resolution(W×H)
Unit Composition(W×H)
Cabinet Resolution(W×H)
Average Power Consumption(W/m²)
Cabinet Weight(kg)
Contrast Ratio
Brightness(nits)
| F1200S09 | F1200C12 | F1200C15 | F1200C18 |
| 320x180 | 240x135 | 192x108 | 160x90 |
| 4x4 | 4x4 | 4x4 | 4x4 |
| 1280x720 | 960x540 | 768x432 | 640x360 |
| 150 | 150 | 130 | 130 |
| 15.6 | 15.6 | 15.6 | 15.6 |
| 10000:1 | 10000:1 | 10000:1 | 10000:1 |
| 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) | 0-600(adjustable) |
|
|
